8 poles magnet for pumps
| Payment Type: | L/C,T/T |
|---|---|
| Incoterm: | FOB,CFR,CIF,EXW,FCA,CPT,CIP |
| Delivery Time: | 30 Days |
Basic Info
Model No.: GWM-358
Application: Motor Magnet
Additional Info
Packaging: PALLET WITH CARTON
Transportation: Ocean,Land,Air
Certificate: ROHS, REACH, ISO9001:2008
Port: SHANGHAI,GUANGHZOU
Product Description
|
Type |
Standard same with TDK | Br(mT) | HcB(kA/m) | Hcj(kA/m) | (BH)max(KJ/m3) |
| Y10T | 200-235 | 125-160 | 210-280 | 6.5-9.5 | |
| Y20 | 320-380 | 135-190 | 140-195 | 18.0-22.0 | |
| Y22H | 310-360 | 220-250 | 280-320 | 20.0-24.0 | |
| Y23 | 320-370 | 170-190 | 190-230 | 20.0-25.5 | |
| Y25 | 360-400 | 135-170 | 140-200 | 22.5-28.0 | |
| Y28H-3 | FB5E | 370±15 | 293±15 | 395±15 | 27±2 |
| Y29H-1 | FB6E | 380±10 | 290±15 | 395±15 | 27±1.6 |
| Y30H-1 | FB3N | 390±10 | 245±15 | 255±20 | 29.5±2.5 |
| Y30H-2 | FB5H | 405±10 | 290±15 | 325±15 | 30.5±2 |
| Y30H-3 | FB4B | 400±10 | 245±15 | 258±15 | 30±2.0 |
| Y30H-4 | FB6H | 400±10 | 305±15 | 360±15 | 30±1.6 |
| Y30H-5 | 400±10 | 300±15 | 400±15 | 30±1.6 | |
| Y32 | FB4A | 410±10 | 175±15 | 180±15 | 32±1.8 |
| Y33 | FB4X | 420±10 | 235±15 | 240±15 | 33±1.8 |
| Y33H | FB5B | 420±10 | 265±15 | 270±15 | 33±2.0 |
| Y33H-2 | FB6B | 420±10 | 300±15 | 320±15 | 33.4±1.6 |
| Y34H-1 | 430±10 | 245±15 | 255±15 | 34±1.6 | |
| Y34H-2 | 430±10 | 260±15 | 280±15 | 34±1.6 | |
| Y34H-3 | 430±10 | 285±15 | 290±15 | 34±1.6 | |
| Y35 | FB5N | 440±10 | 230±15 | 235±15 | 35±1.6 |
| Y36 | FB6N | 440±10 | 259±12 | 362±12 | 36.7±1.6 |
| Y38 | 450±10 | 295±10 | 300±10 | 38.6±2 | |
| Y40 | FB9B | 450±10 | 340±15 | 350±10 | 39.8±2.1 |
